ECG: 3 Channel Electrocardiograph
We are leading suppliers, Dealers and importer of 3 Channel Electrocardiograph and all related medical equipments with high quality machines and offer best after sale services. We offer 3 channel ECG machine. Single or 3 channel display can be adjustable manually. It offers real time measurement and presentation of the parameters. The USB interface and RS232 enable the data transfer to PC. The high efficiency Li battery can work continuously over 2 hours.
Features:
- Compact in size, easy and direct operation, portable
- Accurate pace pulse identification and automatic analysis function
- Four working modes: Manual/Auto/R-R Analysis / Storage
- 12 leads simultaneous waveforms display
- 80mm, single channel format recording
- Advanced [Freeze] function
- 800 x 480 graphic 3.5 inch color LCD
- Built-in USB, RS232 interface, ECGNET software optional
- Built-in rechargeable Ni-MH battery
- 100 patients information storage (Extendable)
- USB interface allows net transmission
- USB flash disk and USB printer connected
Technical Specification:
- Lead: Standard 12 leads
- Lead acquisition: 12bit/l000Hz (synchronously 12 leads)
- Work mode: Manual/ Auto / Physical Examination / Storage
- AC Filter: 50Hz / 60Hz
- EMG Filter: 25Hz / 45Hz
- Anti-Drift Filter: 0.15Hz (Adaptive)
- CMMR: ≥1OOdB (with AC Filter)
- Input circuit: Floating; Protection circuit against Defibrillator effect
- Input impedance: ≥50MΩ
- Input circuit current: ≤ 0.05µA
- Patient current leakage: < 10µA
- Calibrating voltage: 1 mV±2%
- Voltage tolerance: ≥±500mV
- Time constant: ≥3.2s
- Frequency response: 0.05~160Hz (-3db)
- Noise level: < 15µVp-p
- Inter-channel interference: ≤0.5mm
- Sensitivity: Auto. 2.5, 5. 10. 20. 40mm/mV
- Paper speed: 6.25. 12.5, 25, 50mm/s (±3%)
- Paper: 80mm x 20m Roll Paper
- Communication: RS232/ USB port
- Dimension / Weight: 300mm x 230mm x 75mm / 2.8Kg
Power supply:
- AC 110-230V (±10%), 50/60HZ (±1Hz), 60VA
- DC Built-in rechargeable battery. i4.4V(2000mmAh)
Recording mode:
- 3ch, 3ch+
- Default Man. Mode is 3ch format
- Default Auto.Mode is 3ch+ format
